Setup Box Connector

Name: Setup Box Connector
Brand: T T ENTERPRISE
Price: 4.25 INR
Availability: InStock

Price 4.25 INR/ Piece

Get a Price/Quote

MOQ : 10000 Pieces

Setup Box Connector Specification

Power Supply
Passive connector, no power supply required

IP Rating
IP20 (Indoor Use)

Usage
Suitable for digital set top box signal transmission

Operating Temperature
-20C to 60C

Thermal Conductivity
Standard metallic connector high conductivity

Response Time
Instantaneous signal transfer

Interface
Coaxial (RF) Interface

Features
Corrosion resistant, easy plug and play, secure fit, gold plated contacts

Output
Coaxial RF output

Input
Coaxial RF input

Components
Metallic body, central pin, plastic insulation

Product Type
Cable Connector

Application
Set Top Box

Rated Voltage
Up to 250V AC

Size
Standard coaxial connector size

Dimension (L*W*H)
Approx. 26 x 10 x 10 mm

Function
Used for connecting setup or set top boxes to TV or AV systems

Color
Silver

Weight
Approx 10-15 grams

Capacity
Handles standard TV signal frequencies

Thickness
Standard connector thickness, approx 10 mm

Current Rating
Up to 1A max

Frequency
5 MHz - 1000 MHz

Material
Nickel plated brass with plastic insulation

Insertion Loss
< 0.5 dB

Contact Material
Gold plated or tinned copper

Surface Finish
Smooth metallic finish for secure contact

Shielding
Single layer shielding to minimize signal loss

Brand Compatibility
Universal, suitable for all standard set top boxes

Connector Type
RF Coaxial Male/Female

Impedance
75 Ohm

RoHS Compliance
Yes

Durability
Rated for over 1000 mating cycles

Mounting Type
Inline/plug-in

Setup Box Connector Trade Information

Minimum Order Quantity
10000 Pieces

Delivery Time
7 Days

About Setup Box Connector

Jump on the trending new release with our Setup Box Connectorcrafted to elevate your entertainment experience. Monumental in design and first-rate in performance, this universal RF coaxial male/female inline connector boasts a premier nickel-plated brass body and plastic insulation. With single-layer shielding and gold-plated or tinned copper contacts, it guarantees signal integrity while minimizing loss. Compatible with all set top boxes, rated for over 1000 mating cycles, and engineered for instant signal transfer, its the smooth, reliable choice for secure TV and AV connections. Get connectedchoose the ultimate in durability, efficiency, and versatility.

Commercial Applications and Key Advantages

The Setup Box Connector stands out for commercial use in broadcasting operations, electronics distribution, and large-scale AV setups. Its universal compatibility and robust build ensure efficient digital signal transmission for set top boxes. Advantages include instantaneous response time, corrosion resistance, and a secure fit, vital for uninterrupted connectivity. Featuring gold-plated contacts and easy plug-and-play operation, its engineered for over 1000 cycles, delivering remarkable durability and first-rate performance in demanding environments.

Packaging, Export Markets, and Shipping

Packaging details focus on secure shipping with each connector individually sealed and boxed for maximum protection. The main export markets cover Asia, Europe, and North America, with express shipping available from major Indian FOB ports. Proposal amounts are tailored for bulk supply or individual orders, ensuring convenience for distributors and traders. Our packaging ensures safe arrival for importer and supplier needs, making the Setup Box Connector an ideal choice for global delivery requirements.

FAQs of Setup Box Connector:

Q: How does the Setup Box Connector guarantee minimal signal loss during transmission?

A: The connector features single-layer shielding and gold-plated or tinned copper contacts, greatly reducing signal loss and ensuring superior transmission quality for digital TV signals.

Q: What devices are compatible with this Setup Box Connector?

A: This connector offers universal brand compatibility, making it suitable for all standard set top boxes, televisions, and AV systems that use coaxial RF interfaces.

Q: Where is the best location to use the Setup Box Connector?

A: Designed for indoor use, the connector is ideal for home entertainment setups, broadcast centers, hotels, and any environment that requires secure set top box connections.

Q: What is the process for installing the Setup Box Connector?

A: Installation is simplejust plug in the connectors male or female end into the respective RF port of your equipment for instant, secure contact, with no additional power supply needed.

Q: What are the main benefits of using this connector for digital signal transmission?

A: Users benefit from enhanced durability, corrosion resistance, low insertion loss (<0.5 dB), and secure plug-and-play operation, resulting in stable, uninterrupted digital signal transfer.
